Our pebble texture finish HDPE sheet combines the durability of high-density polyethylene with a slip-resistant, easy-to-clean surface. The fine pebble grain provides excellent traction for wet or oily conditions, making it ideal for truck flooring, ramps, animal stalls, washdown areas, and outdoor equipment. UV-stabilized, chemical-proof, and impact-resistant – a low-maintenance alternative to painted steel or checkered plate.
The Pebble Texture Finish HDPE Sheet is a premium thermoplastic panel featuring a uniform, fine-grain pebble pattern on one or both sides. Unlike smooth HDPE, this textured surface significantly improves slip resistance while retaining all the inherent benefits of polyethylene: lightweight, non-absorbent, rot-proof, and resistant to most chemicals, acids, and cleaning agents.
Commonly used as a replacement for diamond plate aluminum, rubber mats, or coated plywood, pebble-finish HDPE offers a hygienic, seamless, and impact-absorbing surface that stands up to heavy foot traffic, wheeled equipment, and constant washdowns.
Feature | Benefit |
|---|---|
Slip resistance | Pebble pattern channels water and debris away, maintaining grip in wet/greasy conditions |
Easy to clean | Non-porous surface resists bacterial growth; hoses off instantly |
Aesthetic uniformity | Consistent fine texture hides scratches and wear better than smooth sheets |
No paint to peel | Color is integral throughout the sheet – never chips, flakes, or rusts |
Soft underfoot | Provides slight cushioning compared to metal, reducing fatigue for standing workers |
Material: High-Density Polyethylene (HDPE) – virgin or recycled content available
Finish: Pebble grain (matte, low-glare) – one side or both sides textured
Colors: Black, gray, white, tan, blue, red, yellow, green (custom colors available)
UV Stabilization: Yes (additives resist sunlight degradation – suitable for outdoor use)
FDA Compliance: Available in food-contact grade (USDA / FDA approved for indirect contact)
Temperature range: -60°F to +180°F (-51°C to +82°C)
Water absorption: <0.01% (effectively zero)
Industry | Use Case |
|---|---|
Transportation | Truck bed liners, trailer flooring, van wall panels, livestock trailer floors |
Marine | Dock fenders, boat decking, fish hold liners, dock bumpers |
Agriculture | Horse stall mats, feeding trough liners, stable walls, livestock wash pads |
Industrial | Workstation flooring, anti-fatigue layering, chute liners, conveyor wear strips |
Food processing | Cutting board surfaces, washdown station flooring, equipment guards |
Recreation | Skate park ramps, playground surfaces, dog park agility equipment |
Construction | Temporary walkway sheets, equipment skid plates, ramp surfacing |
Parameter | Standard Value |
|---|---|
Thickness range | 1/8" (3 mm) to 1" (25 mm) |
Sheet size (standard) | 48" x 96" (1220 x 2440 mm) |
48" x 120" (1220 x 3050 mm) | |
60" x 120" (1524 x 3050 mm) | |
Texture depth | Approx. 0.010" – 0.020" (0.25 – 0.5 mm) |
Tensile strength (yield) | 4,000 – 5,000 psi |
Shore hardness | D 65 – 70 |
Coefficient of friction (dry) | 0.55 – 0.65 (ASTM D1894) |
Coefficient of friction (wet) | 0.45 – 0.55 |
Texture | Slip Resistance | Cleanability | Best For |
|---|---|---|---|
Pebble (fine grain) | ★★★★☆ | ★★★★★ | Wet areas, food processing, truck beds |
Diamond (raised embossed) | ★★★★★ | ★★★☆☆ | Ramps, forklift traffic |
Orange peel (light texture) | ★★★☆☆ | ★★★★★ | Vertical surfaces, signage |
Smooth | ★☆☆☆☆ | ★★★★★ | Glide surfaces, liners |
Sand-grip (embedded grit) | ★★★★★ | ★★☆☆☆ | Extreme slip-prone areas (but hard to clean) |
Material | Pebble HDPE Advantage |
|---|---|
Diamond plate aluminum | No corrosion, non-conductive, quieter, softer on knees |
Rubber mats | No odor, no water absorption, no mold/mildew, easier to slide loads |
Plywood / OSB | Never rots, no splinters, chemical resistant, washable |
Coated steel | No rust, no chipping paint, lighter weight, impact absorbing |
Smooth HDPE | Much better slip resistance, hides scratches |
Pebble texture HDPE can be worked with standard woodworking or metalworking tools:
Cutting: Circular saw (carbide blade), band saw, jigsaw, waterjet, CNC router
Drilling: Standard HSS or carbide drill bits – allow 0.005"–0.010" oversize for thermal expansion
Fastening: Accepts screws, bolts, rivets – pre-drill to prevent cracking
Welding: Can be hot-air or extrusion welded for seamless joints (same material)
Bending: Heat-forming possible (thermoforming); cold bending not recommended
Routine: Hose down or pressure wash (up to 3,000 psi)
Stubborn stains: Mild detergent and soft brush – pebble texture will not trap debris if rinsed properly
Sanitizing: Bleach solutions, steam, or food-grade sanitizers do not degrade HDPE
Do not use: Abrasive pads (may smooth texture), strong oxidizing acids (nitric, sulfuric >50%), or temperatures above 180°F
Recyclable – HDPE is #2 plastic, widely accepted in recycling programs
Non-toxic – Contains no lead, BPA, or phthalates (FDA grades available)
Low VOC – No off-gassing or odor after manufacturing
Non-conductive – Safe for electrical environments (up to moderate voltages)
Option | Details |
|---|---|
Texture location | Single side (smooth back) or double side (pebble both sides) |
Edge finish | Raw cut, rounded, beveled, or tongue-and-groove |
Custom colors | Matched to RAL or Pantone (minimum order quantity applies) |
Die-cutting | Custom shapes, hole patterns, and cutouts available |
Lamination | Bonded to plywood, aluminum, or FRP for added stiffness |
Anti-static | Conductive or static-dissipative grades available |
Thickness | Typical Weight (per 4'x8' sheet) | Common Uses |
|---|---|---|
1/8" (3mm) | 15 lbs | Wall liners, light-duty covers |
1/4" (6mm) | 30 lbs | Truck beds, horse stall mats |
3/8" (10mm) | 45 lbs | Trailer flooring, work platforms |
1/2" (12mm) | 60 lbs | Heavy equipment liners, ramps |
3/4" (19mm) | 90 lbs | Industrial flooring, crane outrigger pads |
1" (25mm) | 120 lbs | Extreme duty pads, dock bumpers |
Cut-to-size pieces available. No minimum order for standard black – custom colors require 10+ sheets.
✅ True pebble texture – Uniform pattern across entire sheet, no blank spots
✅ USA/European manufacturing options – Consistent quality control
✅ Same-day shipping on in-stock sheets up to 4'x8'
✅ Custom fabrication – Cut, drill, route, or weld to your print
✅ Bulk pricing – Volume discounts for 25+ sheets
We offer 12" x 12" sample coupons for $10 (refundable with first order). See and feel the pebble texture before buying full sheets.
✅ Pebble texture finish – Fine anti-slip grain pattern, excellent traction wet or dry
✅ 100% HDPE – No rot, no rust, no paint to peel, no splinters
✅ Easy to clean – Non-porous surface, hose off mud, blood, grease, or chemicals
✅ UV stabilized – Won't crack or fade in sunlight – ideal for outdoor use
✅ Impact resistant – Absorbs shock without breaking – great for truck beds and stalls
✅ Chemical proof – Resists diesel, hydraulic fluid, bleach, acids, and saltwater
✅ FDA compliant option – Food contact safe for cutting boards and processing tables
